SQ160011

Specifications

• Power RMS 1Ω @ 14.4V: 1 x 1600W
• Power RMS 2Ω @ 14.4V: 1 x 880W
• Power RMS 4Ω @ 14.4V: 1 x 484W
• THD+N @ Nominal Power: <1%
• Frequency Response: 10Hz ~ 30kHz
• SNR: 96dB
• Input Sensitivity: 0.5V to 8V
• Dimensions: 9" W x 7-1/4" L x 2-1/8" H



• Damping Factor: >1000
• Operating Voltage: 9V to 16V
• High Pass Filter: 5Hz to 80Hz
• Low Pass Filter: 50Hz to 500Hz
• Total Efficiency: 73%
• Max Current Draw (A): 174
• Music Current Draw (A): 87
