SSQ12001

Specifications

• Power RMS 1Ω @ 14.4V: 1 x 1200W
• Power RMS 2Ω @ 14.4V: 1 x 900W
• Power RMS 4Ω @ 14.4V: 1 x 600W
• THD+N @ Nominal Power: 1 x 1%
• Frequency Response: 20Hz ~ 450Hz
• SNR: <78dB(1W)
• Dimensions: 351*170*48mm



• Input Sensitivity: 0.22-5.2(±10%)
• Damping Factor: 115(4Ω) 115(4Ω)
• Operating Voltage: 6.5-15.8(±0.3)
• High Pass Filter: 20-35Hz(±3)
• Low Pass Filter: 50-450Hz(±10)
• Total Efficiency: 82%(4Ω)
• Max Current Draw (A): 82
• Music Current Draw (A): 55
