EL10005
5-Channel Class D Amplifier
2000 Watts
Peak PowerFIVE
Channel4 Ohm
ImpedanceD
ClassEL1000.5
5-Channel Class D Amplifier- Power RMS 4Ω @ 14.4V: 4 x 125W + 1 x 500W
- Power RMS 8Ω @ 14.4V: 4 x 80W + 1 x 300W
- Power RMS Bridged 8Ω @ 14.4V: 2 x 250W
- THD+N @ Nominal Power: <1%
- Frequency Response (-3db): 20Hz ~ 150kHz
- SNR: 90dB
- Input Sensitivity: 0.2 ~ 6V
Specifications
- High Pass Filter: 50Hz ~ 500Hz
- Low Pass Filter: 50Hz ~ 500Hz
- Damping Factor: 260
- Bass Boost: Adjustable 0-12dB
- Bass Boost Center Frequency: 45Hz
- Dimensions: 11.9” x 6.9” x 2.1”
